SDI Diagnostics AstraTouch Spirometer, 29-5400

The AstraTouch™ Desktop Spirometer provides easy navigation when performing comprehensive spirometry testing. Its multifunctional capabilities provide a means of making a diagnostic decision from the screen data, from its resident printer or off-line report writers. PC links via USB or optional Bluetooth make easy work of storing data archivally, transferring tests to EMR or performing real- time direct testing.

The AstraTouch™ Spirometer was designed to be easy to use while providing accurate and precise testing data. The simplicity of operation and wealth of configurability options expand the scope of spirometry testing like never before. Review and enter data, make a diagnosis, print a report or download to EMR quickly and with minimal effort.

Features:

Full color touchscreen display
AccuFlo digital turbine
Flow-trigger, patient-initiated testing
Measures over 40 parameters of FVC, VC, MVV
Bluetooth PC Communications
Choice of 16 predicted sets
AstraPro software
On-board thermal printer
Meets NIOSH standards
Test quality assurance prompts
Four selectable interpretations
Automated maneuver acceptability
Bronchial challenge module
No proprietary disposables
Audible end-of test-alert
Pulse Oximetry (Optional)
MIP/MEP (Optional)
Weather station (Optional)
Ethernet connectivity (Optional)
Quick and easy data entry, navigation
Accuracy and precision without calibration
Better patient cooperation
Meets any needs of the clinician
Speedy wireless interface for interactive testing
Flexibilty of choice
Realtime PC testing, archiving or EMR
Quick test results
Disability testing-capable
Enhances test quality
Choice for the clinician
Quality test assurance
Expands testing capabilities
Reduces cost-of-ownership
Assures patient effort
Added testing capability
Added testing capabilities
Ensures accurate calibration
Maximizes communication, telemedicine, capabilities

Technical Specifications:

Forced Parameters Measured

Forced vital capacity: FVC, FEV1, FEV1/FVC, PEF, FEF50%,FEV6, FEV1/FEC, PEF, FEF50%, FEF25-75%, FEV6,FEV1/ FEV0.5, PEFT, Vext, FIVC, FIF50%, FEF50/FIF50, QC Grades, FEV.5, FEV3, FEV.5/FVC,FEV3/ FVC,FEV1/VC, FEV1/FEV6, FEV1/PEF, FEV1/FIV1, PEF/PIF, FEF25%, FEF75%, FEF75-85%, FET25-75%, FET100, FIV1, FIV1/FIVC, PIF, MTT, MVVInd, Lung age
MVV: MVV, Br./min
Bronchoconstriction: FVC, FEV1, PEF, FEF25-75%, PDx

Relaxed Parameters Measured

VC: VC, TV, ERV, IRV, IC, Ti, Te, Tt, Ti/Tt

Maneuvers per patient: 8 total; best test and last test highlighted
Interpretation: Selectable – Kory, Miller, ATS, NLHEP (Ferguson)
Predicted sets: Selectable – 16 Total
Ethnic correction: Selectable – % Actual, Caucasian, Hispanic, AfroAmerican
Language: Selectable – English, Spanish or French

Measurement Scale (BTPS)

Flow range: 0–16 L/sec
Volume: 0–10 L
Measurement method: Infrared Interruption via Digital Turbine
Dynamic flow resistance: <1.5 cm H20/L/sec @ 14 L/sec

Measurement Precision (BTPS)

At highest volume: +/- 3% or 50 mL
At highest flow: +/- 5% or 150 mL
Time related precision: .5%
Volume resolution: <6 mL
Sampling frequency: 50 Hz

Hardware Specifications

Storage capacity: 3000+ study database
Display: 5.7" High resolution color VGA touchscreen
Communication: USB to printer and PC, RS232, HL-7* Optional: Bluetooth to PC
Dimensions: 7.7" x 10.6"x 3.9"
Power supply: 2 x 1.5 DC Alkaline or NiMH batteries
Weight: 3.7 lbs
Storage temperature: -4 to 158 F
Printer: 110 mm thermal graphic printer

What is in the box?

Astra Touch Screen Spirometer w/ Printer
AstraPro Software
10 Mouthpieces
10 Noseclips
AccuFlo digital turbine
2 Rolls Paper
1 Quick Reference Card

Ordering:
29-5400: AstraTouch Spirometer
29-5400-050: AstraTouch Spirometer Kit (AstraTouch, 50 AstraGuard Filters, 50 Kushion Klip noseclips)
29-5401: AstraTouch Spirometer Kit (AstraTouch, Calibration Syringe)
29-5401-050: AstraTouch Spirometer Kit (AstraTouch, Calibration Syringe, 50 AstraGuard Filters, 50 Kushion Klip noseclips)
29-5403: AstraTouch Spirometer Kit (AstraTouch with Pulse Oximeter Module, Adult Finger Probe)
29-5403-050: AstraTouch Spirometer Kit (AstraTouch, Pulse Oximeter Module, Adult Finger Probe, 50 AstraGuard filters, 50 Kushion Klip noseclips)
29-5403S: AstraTouch Spirometer Kit (AstraTouch, Calibration Syringe, Pulse Oximeter Module, Adult Finger Probe)
29-5403S-050: AstraTouch Spirometer Kit (AstraTouch, Calibration Syringe, Pulse Oximeter Module, Adult Finger Probe, 50 AstraGuard Filters, 50 Kushion Klip noseclips)
29-5405: AstraTouch Spirometer Kit (AstraTouch, Rechargeable Battery)
29-5405-050: AstraTouch Spirometer Kit (AstraTouch, Rechargeable Battery, 50 AstraGuard Filters, 50 Kushion Klip noseclips)
29-5405S: AstraTouch Spirometer Kit (AstraTouch, Rechargeable Battery, Calibration Syringe)
29-5405S-050: AstraTouch Spirometer Kit (AstraTouch, Rechargeable Battery, Cal Syringe, 50 AstraGuard Filters, 50 Kushion Klip noseclips)
29-5405PO: AstraTouch Spirometer Kit (AstraTouch, Rechargeable Battery, Pulse Oximeter Module, Adult Finger Probe)
29-5405PO-050: AstraTouch Spirometer Kit (AstraTouch, Rechargeable Battery, Pulse Oximeter Module, Adult Finger Probe, 50 AstraGuard Filters, 50 Kushion Klip noseclips)
29-5405SPO: AstraTouch Spirometer Kit (AstraTouch, Rechargeable Battery, Pulse Oximeter Module, Adult Finger Probe, Calibration Syringe)
29-5405SPO-050: AstraTouch Spirometer Kit (AstraTouch, Rechargeable Battery, Pulse Oximeter Module, Adult Finger Probe, Calibration Syringe, 50 AstraGuard Filters, 50 Kushion Klip noseclips)
