Richmar (previously Roscoe) SoundCare Plus Professional Ultrasound Device DQ9275

The SoundCare Plus is a professional ultrasound device, designed by clinicians. With this unique design, the SoundCare Plus comes equipped with two applicators, 1cm² and 5cm², that are plugged into the device allowing the user to switch between applicators with a single button push.The SoundCare Plus has 20 presets and operates in 1 MHz and 3 MHz frequencies. The portable design lets you take it to your patient or keep it at the clinic. It’s easy to use, and up and running within minutes.

For the treatment of chronic and acute muscular pain
Includes two applicators, 1cm² and 5cm²
Fully functional 1 MHz and 3 MHz frequencies
Simultaneously switch between applicators with the push of a single button
10 user-defined presets with pulsed and continuous therapy
Variable duty cycle outputs
Ergonomic handle design
Two-year warranty

TECHNICAL SPECIFICATIONS

Acoustic Frequency: 1 MHz ± 10%, 3 MHz ± 10%
Output Power: 0.5 - 10.0 W ± 20%, when duty factor > 80% for 5 cm2 0.5 - 15.0 W ± 20%, when duty factor < 70% for 5 cm2 0.1 - 2.0 W ± 20%, when duty factor > 80% for 1 cm2 0.1 - 3.0 W ± 20%, when duty factor < 70% for 1 cm2
Pulse Repetition Rate: 100 Hz ± 10% • Duty Factor: 10% - 100%, Stepping 10%
Timer: Max 30 minutes
Effective Radiating Area: 5.0 cm2 ± 20%; 1.0 cm2 ± 20%
Actual Intensity: 3.0 w/cm2 ± 20% (1.0 MHz) 3.0 w/cm2 ± 20% (3.0 MHz)
Raw (Max): 5.0
Beam Type: Collimated
Material of Applicator: Aluminum
Waterproof Grade: IPX7 only for treatment head
