Bovie Derm942 High Frequency Desiccator 40W A942

Special Price $859.00 Regular Price $1,242.83
In stock
SKU
A942
Bovie Medical Manufactured by Bovie Medical
free shipping
extended warranty
30 Days Return
Add to Wish List
Request A Quote

Bovie Derm942 High Frequency Desiccator 40W A942

Designed For Years of Trouble-Free Use
The Bovie Derm 942 is designed and engineered to be the most reliable and durable desiccator available today. The unit’s life is prolonged by incorporating the latest in chip technology and reducing the number of internal parts, thereby generating less internal heat. Post-procedure and long-term cleanup are simplified by its non-absorbing, non-staining, high impact plastic case.

Bovie A942 Electrosurgical Generator

A) POWER SWITCH
Turn the unit power on utilizing the switch on the left side panel of the unit.

B) POWER OUTPUT DIAL
Set the power output either by using the dial on the left side of the unit or by the up and down buttons on the handpiece (F). When power level adjustment is being made by the handpiece an audible tone will sound to indicate that the power level has been changed. Depressing and holding the up or down buttons will cause the power settings to change more rapidly for quick adjustment of the output settings. Power output is displayed in “.1” watt increments from 0.1 to 10 watts.

C) ACTIVE LIGHT
When the unit is activated, an audible tone is sounded and the blue active light will illuminate.

D) STANDARD ELECTRODE
Slide the standard electrode into the handpiece until it is firmly seated. The handpiece will accept most standard 3/32″ electrodes.

E) ACTIVATION BUTTON
To activate the unit, remove the handpiece from the holder. Place the handpiece in the desired position and depress the activation button.

F) POWER OUTPUT BUTTONS
Set the power output by pressing the up and down buttons on the handpiece.

G) MONOPOLAR OUTPUT RECEPTACLE
The monopolar output for the handpiece is on the lower right front of the unit. The handpiece plug is designed to fit in only one direction. Plug the connector from the handpiece into the receptacle on the bottom of the unit. The three button handpiece is designed to give the doctor complete fingertip control of the power output settings.

H) GROUNDING PLATE OUTPUT RECEPTACLE
To use the optional grounding plate with cord (A802EU), insert the plug of the cord into the grounding plate output receptacle (H) and connect the other end into the grounding plate. The plate should be placed underneath the patient at a point where the entire plate is covered by bare skin. The use of conductive gel is recommended.

I) BIPOLAR OUTPUT RECEPTACLE
To use bipolar forceps, you need the following optional accessories, bipolar cord #A827V, footswitch #A803 and a bipolar forceps (please refer to the catalog to choose the right forceps for your particular procedure). Insert the plug into the bipolar outputs receptacle (I), then connect the cord to the forceps.

J) POWER CORD
Plug the female end of the power cord into the base of the unit.

K) FOOTSWITCH OUTPUT RECEPTACLE
The optional footswitch (A803) is plugged into the footswitch output and placed on the floor. The footswitch can be used with monopolar procedures and must be used with bipolar procedures.

Package Includes:

  • A942 – Electrosurgical Generator (1ea)
  • A902 – 3-Button Power Control & Autoclavable Handpiece (1ea)
  • A804 – Sharp Dermal Tips, Non-Sterile (5ea)
  • A805 – Sharp Dermal Tips, Sterile (2ea)
  • A806 – Blunt Dermal Tips, Non-Sterile (5ea)
  • A807 – Blunt Dermal Tips, Sterile (2ea)
  • A806DE – DERM-Elite™ Premium Blunt Dermal Tip, Non-Sterile (2ea)
  • A807DE – DERM Elite™ Premium Blunt Dermal Tip, Sterile (2ea)
  • A910 – Disposable Handpiece Sheath, Non Sterile (2ea)
  • A910ST – Disposable Handpiece Sheath, Sterile (2ea)
  • A837 – Wall Mount Kit (1ea)
  • Medical Grade Power Cord
  • User Manual (CD Format)

TECHNICAL SPECS

  • MONOPOLAR: Spray Coagulation
  • WATTS: 40W
  • VPEAK MAX VOLTAGE: 6300V
  • Crest Type (typical)9.5 ± 20%
  • FREQUENCY (KHZ): 410 kHz ± 82.0 kHz
  • Bipolar: Standard Bipolar
  • WATTS: 40W
  • VPEAK MAX VOLTAGE: 950V
  • Crest Type (typical )5.5 ± 20%
  • FREQUENCY (KHZ): 368 kHz ± 36.8 kHz
  • Line Frequency: 50–60 Hz
  • Output Frequency: 328-492 kHz
  • Line Voltage: 100-240 VAC
  • Output Power: Fulguration: 40 watts Bipolar: 40 watts
  • Cooling System: Passive Cooling
  • Technology: Isolated RF Output
  • Audible/Visible Output Meter: Yes
  • Pre-set Feature: No
  • Monopolar HP Ports: 1
  • Connector Ports/Power Switch: White
  • Weight: < 2.26 kg (< 5 lbs.)
  • Dimensions: Height: 188 mm (7.40 in.) Width: 228 mm (8.98 in.) Depth: 105 mm (4.13 in.)
