Roscoe Medical ComboCare 2 ch. E-Stim & Ultrasound Unit DQ7844

Unique in nature, the SoundCare™ Plus professional ultrasound device comes complete with two sound heads that can be plugged in simultaneously for more targeted therapy. Simple to operate, the user can switch between wands with the single push of a button.

Features:

• Two channels of electrical stimulation output
• Large easy-to-read graphical LCD display with exact dial performance and programmable timer
• Waveforms include TENS, EMS, 2-Pole Interferential, 4-Pole Inteferential and Russian
• Dual clinical ultrasound features a 5 cm sound head which offers 1 MHz and 3 MHz frequencies
• Ultrasound has 10% - 100% duty cycle selections
• 10 presets per waveform totaling 50 in all
• 20 ultrasound presets
• User defined memory positions for user protocols
• Designed for tabletop, therapy cart or mobile use
• Includes eight sets of electrodes, eight sets of rubber electrodes with sponges, eight straps, four sets of lead wires and a user manual
• Product dimensions: 10 ½” (W) x 15” (L) x 8” (H)
• Product weight: 6.7 lbs
• Two year warranty

Specifications:

• Wavelength: IFC-4P, IFC-2P, TENS, EMS and Russian
• Pulse Width: 30-40 µs
• Frequency: 1 MHz and 3 MHz for ultrasound, 1-250 Hz for LF, beat frequency for IF: 1-150 Hz, carrier frequency for IF: 4KHz, carrier frequency for Russian: 2.5KHz
• Power Supply: Adaptor, input 100-240V 50/60 Hz, output 15V/3A
• Intensity: Max 3W/CM2 (pulse) for ultrasound, 0-50mA for IF (IKΩ), 0-100mA for LF (IKΩ)
• Working Time: Max 60 minutes for IF, Max 30 minutes for ultrasound and combo
• Dimensions: 9.8” x 7.3” x 3.2”
• Weight: 5.5 lbs.
• Working Environment: Temperature: 10°C - 40°C Humidity: 30% RH to 85% RH Atmospheric Pressure: 800hPa - 1060hPa
• Storage Environment: Temperature: 10°C - 55°C Humidity: 20% RH to 85% RH Atmospheric Pressure: 700hPa - 1060hPa
